Technics SU-C04

It employs a new class A method using a synchronous bias circuit unique to Technics and eliminates switching distortion, which is the cause of sound turbidity.

Es verwendet eine neue Klasse-A-Methode mit einer synchronen Bias-Schaltung, die es nur bei Technics gibt, und eliminiert Schaltverzerrungen, die die Ursache für Trübungen sind.

Specifications:

• Power output: 30 watts per channel into 8Ω (stereo)

• Frequency response: 5Hz to 100kHz

• Total harmonic distortion: 0.007%

• Damping factor: 60

• Input sensitivity: 2.5mV (MM), 150mV (line)

• Signal to noise ratio: 82dB (MM), 98dB (line)

• Channel separation: 55dB (line)

• Output: 150mV (line), 30mV (DIN)

• Speaker load impedance: 6Ω to 16Ω

• Dimensions: 297 x 74 x 230mm

• Weight: 4.5kg
